Product details
| *Frame | Size: S Alpha Gold Aluminium, curved top tube, DuoTrap S-compatible, internal cable routing, rack and mudguard mounts, post-mount disc, kickstand mount, 135x5 mm QR |
|---|---|
| Size: M, L, XL Alpha Gold Aluminium, DuoTrap S-compatible, internal cable routing, rack and mudguard mounts, post-mount disc, kickstand mount, 135x5 mm QR |
|
| Fork | SR Suntour NEX, coil spring, preload, hydraulic lockout, 100x5 mm QR, 63 mm travel |
Wheels
| Hub front | Dynamo, 6V 3.0 W, 100x5 mm QR |
|---|---|
| Hub rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
| Skewer rear | 152x5 mm QR |
| Rim | Bontrager Connection, alloy, double-wall, 32-hole, Schrader valve |
| Tyre | Bontrager H2 Comp, reflective strip, wire bead, 30 tpi, 700x40 mm |
| Max tyre size | Frame: 700x45mm with mudguards, 29x2.10" without mudguards, Fork: See manufacturer |
Drivetrain
| Shifter | Shimano Altus M2010, 9-speed |
|---|---|
| Front derailleur | Shimano Acera T3000, 34.9 mm clamp, top swing, dual pull |
| Rear derailleur | Shimano Altus M2000, long cage |
| Crank | Forged alloy, 46/30, chainguard, 170 mm length |
| Bottom bracket | Sealed cartridge, 68 mm |
| Cassette | Shimano HG200, 11-36, 9-speed |
| Chain | KMC X9 |
| Pedal | Wellgo M141, resin body, alloy cage |
Components
| Saddle | Bontrager Sport |
|---|---|
| Seatpost | Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length |
| *Handlebar | Size: S, M Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width |
| Size: L, XL Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width |
|
| Grips | Bontrager Satellite |
| *Stem | Size: S Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length |
| Size: M, L Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length |
|
| Size: XL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length |
|
| Head set | 1-1/8" threadless, sealed cartridge bearings |
| Brake Set | Tektro HD-M275 hydraulic disc, 160 mm rotor |
Accessories
| *Light | Size: S, M, L, XL Herrmans H-Trace ECO dynamo LED |
|---|---|
| Size: S, M, L, XL Spanninga Brio, 15 Lux, LED headlight |
|
| Kickstand | Alloy, rear-mount kickstand |
| *Mudguard | Size: S, M, L, XL SKS plastic, front |
| Size: S, M, L, XL SKS plastic, rear |
Weight
| Weight | L - 15.40 kg/33.96 lb |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| Sizing | ||
|
Size-table |
||
| Size | Rider Height | Inseam |
| XS | 147 - 155 cm | 69 - 73 cm |
| 4'10" - 5'1" | 27" - 29" | |
| S | 155 - 165 cm | 72 - 78 cm |
| 5'1" - 5'5" | 28" - 31" | |
| M | 165 - 175 cm | 77 - 83 cm |
| 5'5" - 5'9" | 30" - 33" | |
| L | 175 - 186 cm | 82 - 88 cm |
| 5'9" - 6'1" | 32" - 35" | |
| XL | 186 - 197 cm | 87 - 93 cm |
| 6'1" - 6'6" | 34" - 37" | |
