Product details
| *Frame | Size: XXS , XS , S , M , ML , L , XL , XXL Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew |
|---|---|
| Size: XXS , XS Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew |
|
| *Fork | Size: XXS RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel |
| Size: XS , S RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel |
|
| Size: M , ML , L , XL , XXL RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel |
Wheels
| Hub front | Formula DC-20 LW, alloy, 6-bolt, 5x100 mm QR |
|---|---|
| Hub rear | Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
| Skewer rear | Bontrager Switch thru axle |
| *Rim | Size: XXS , XS , S Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve |
| Size: M , ML , L , XL , XXL Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve |
|
| *Tyre | Size: XXS Maxxis Ardent, tubeless, EXO casing, folding bead, 60tpi, 26x2.40" |
| Size: XS , S Maxxis Ardent, tubeless, EXO casing, folding bead, 60tpi, 27.5x2.40" |
|
| Size: M , ML , L , XL , XXL Maxxis Ardent, tubeless, EXO casing, folding bead, 60tpi, 29x2.40" |
Drivetrain
| Shifter | SRAM SX Eagle, 12-speed |
|---|---|
| Rear derailleur | SRAM SX Eagle |
| *Crank | Size: XXS SRAM SX Eagle, 30T steel ring, 49 mm chainline, 155 mm length |
| Size: XS , S , M SRAM SX Eagle, 30T steel ring, 49 mm chainline, 170 mm length |
|
| Size: ML , L , XL , XXL SRAM SX Eagle, 30T steel ring, 49 mm chainline, 175 mm length |
|
| Bottom bracket | Truvativ Powerspline, 73 mm, threaded cartridge, 118 mm spindle |
| Cassette | SRAM PG-1210 Eagle, 11-50, 12-speed |
| Chain | SRAM SX Eagle, 12-speed |
| Pedal | Wellgo VPE-536 |
Components
| Saddle | Bontrager Arvada, steel rails, 138 mm width |
|---|---|
| *Seatpost | Size: XXS , XS , S TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length |
| Size: M TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length |
|
| Size: ML , L , XL , XXL TranzX JD-YSP18, 150mm travel, internal routing, 31.6 mm, 470mm length |
|
| *Handlebar | Size: XXS , XS Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width |
| Size: S Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width |
|
| Size: M , ML , L , XL , XXL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
|
| Grips | Bontrager XR Trail Comp, nylon lock-on |
| *Stem | Size: XXS , XS , S Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 35 mm length |
| Size: M , ML , L Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length |
|
| Size: XL Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length |
|
| Size: XXL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length |
|
| Head set | Semi-integrated, 1-1/8" |
| Brake | Shimano MT200 hydraulic disc |
| *Brake rotor | Size: XXS , XS , S , M , ML , L , XL , XXL Shimano RT26, 6-bolt,160 mm |
| Size: M , ML , L , XL , XXL Shimano RT26, 6-bolt,180 mm |
|
| Brake Set | Shimano MT200 hydraulic disc |
Weight
| Weight | M – 14.29 kg/31.51 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lbs). |
| Sizing | ||
|
Size-table |
||
| Size | Rider Height | Inseam |
| 44 | 150 - 153 cm | 71 - 73 cm |
| 4'11" - 5'0" | 28" - 29" | |
| 47 | 152 - 158 cm | 71 - 75 cm |
| 5'0" - 5'2" | 28" - 30" | |
| 50 | 158 - 163 cm | 74 - 77 cm |
| 5'2" - 5'4" | 29" - 30" | |
| 52 | 163 - 168 cm | 76 - 79 cm |
| 5'4" - 5'6" | 30" - 31" | |
| 54 | 168 - 174 cm | 78 - 82 cm |
| 5'6" - 5'9" | 31" - 32" | |
| 56 | 174 - 180 cm | 81 - 85 cm |
| 5'9" - 5'11" | 32" - 33" | |
| 58 | 180 - 185 cm | 84 - 87 cm |
| 5'11" - 6'1" | 33" - 34" | |
| 60 | 185 - 190 cm | 86 - 90 cm |
| 6'1" - 6'3" | 34" - 35" | |
| 62 | 190 - 195 cm | 89 - 92 cm |
| 6'3" - 6'5" | 35" - 36" | |
