Frame

OCLV Mountain Carbon main frame and stays, IsoStrut, tapered head tube, Knock Block, Control Freak internal routing, Boost148, 60 mm travel

Fork

RockShox 35 Gold RL, DebonAir spring, Motion Control damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel

*Shock

Size: S
Trek IsoStrut, Fox Performance shock, air spring, DPS 2-position remote damper, 235x32.5 mm

Size: M , L , XL
Trek IsoStrut, Fox Performance shock, air spring, DPS 2-position remote damper, 235 mm x 32.5 mm

Max compatible fork travel

120mm (531mm axle-to-crown)

Hub front

Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle

Hub rear

Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano MicroSpline freehub, Boost148, 12 mm thru axle

Skewer rear

Bontrager Switch thru axle, removable lever

Rim

Bontrager Kovee Comp, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve

Tyre

Bontrager XR3 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.40"

Tyre part

Bontrager TLR sealant, 180 ml/6 oz

Max tyre size

Frame: 29x2.40" Fork: See manufacturer

Shifter

Shimano Deore M6100, 12-speed

Rear derailleur

Shimano XT M8100, long cage

Cassette

Shimano Deore M6100, 10-51, 12-speed

Chain

Shimano Deore M6100

Max. chainring size

32T with 52mm chainline

Saddle

Bontrager Arvada, hollow chromoly rails, 138 mm width

*Seatpost

Size: S
TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length

Size: M , L , XL
TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length

*Handlebar

Size: S
Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width

Size: M , L , XL
Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750 mm width

Grips

Bontrager XR Trail Comp, nylon lock-on

*Stem

Size: S , M
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree, 60 mm length

Size: L , XL
Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0-degree, 70 mm length

Brake

Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper

Brake rotor

Shimano RT66, 6-bolt, 180mm

E-bike system

Fazua Ride Trail 50 motor

Battery

Fazua Evation battery, 250 Wh

Charger

Fazua Evation charger, 220-240V

Controller

Fazua Remote bX

Weight

M - 18.48 kg / 40.75 lbs (with TLR sealant, no tubes)

Weight limit

This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).

المقاسات

جدول المقاسات

Size

Rider Height

Inseam

S

155 - 165 cm

74 - 78 cm

5'1" - 5'5"

29" - 31"

M

165 - 176 cm

79 - 83 cm

5'5" - 5'9"

31" - 33"

L

177 - 188 cm

84 - 89 cm

5'10" - 6'2"

33" - 35"

XL

188 - 195 cm

89 - 91 cm

6'2" - 6'5"

35" - 36"
